Centrifugal Spinning Concrete Pipe making Machine

Centrifugal Spinning Concrete Pipe making Machine

Working Principle:

LWC series is the traditional Hume Concrete Pipe making machine; the most popular equipment to produce the reinforced Concrete pipes over the 20 years.

Supporting wheels will be driven by the motor, High speed rotation will produce centrifugal acceleration; the concrete mixture will be congregated into the inner wall of mould and becomes density and solid at the function of the centrifugal force. Exhausting the extra water and air, the Concrete will form the standard  quality concrete pipe.

Features:

1.      Easy to operate, good performance,

2.      High rate of final pipes, smooth surface of pipe,

3.      Capacity: 200-2000mm, Length 2-4 meter

4.      Pipe end joint: Flat, Tonuge&groove, Spigot&socket.

5.      Application: Concrete pipes Water Drainage, Storm Water, Sewage pipes, Agricultural Irrigation, Road Culvert, Power Plant Water treatment.

Technical Details

Item

LWC600

LWC1200

LWC1600

Pipe Diameter

300-600mm

800-1200mm

1200-1600mm

Pipe Length

2-4 m

2-4 m

2-4 m

Wheel  Distance

950 mm

1140 mm

1420 mm

Wheel  Material

45# Cast Steel

Motor Power

VF-15-22 KW

VF-30-45 KW

VF-55-75 KW

Rotation Speed

60-600 r/min  4 step control
